The Stainless Steel Trapezoidal Metal Roof Clamp is a high-strength, corrosion-resistant fastening device designed for securing solar mounting systems or other fixtures to trapezoidal-profile metal roofs. Engineered specifically to conform to the unique geometry of trapezoidal sheets, this clamp provides a secure, reliable attachment point without the need for through-bolting in many applications (though some designs utilize a bolt for enhanced pull-out resistance). Its all-stainless-steel construction ensures exceptional durability in harsh environmental conditions.

Key Features:

• Heavy-Duty Material: Manufactured from high-grade stainless steel (typically SS304 ), offering superior resistance to rust, corrosion, and UV degradation. This makes it ideal for coastal areas, industrial zones, and regions with high humidity or acid rain.

• Trapezoidal Profile Compatibility: The base of the clamp is precisely contoured to match the angles and flats of standard trapezoidal metal roof sheets. It is designed to sit flush on the crest (top) of the rib, distributing load evenly.

• Dual-Action Grip: Employs a robust clamping mechanism that, when tightened, compresses against the sides and/or top of the trapezoidal rib, creating a strong mechanical bond without deforming the metal sheet.

• Integrated Seal Protection: Features a pre-installed EPDM rubber gasket or pad on the contact surface. This compressible seal protects the roof's paint finish, dampens vibration, and provides a watertight barrier against capillary action.

• Versatile Top Connection: The top of the clamp typically features a pre-drilled hole or a threaded stud (M8, M10, or M12) to allow for easy attachment of mounting hardware, such as L-feet, mini rails, or square tube brackets.

Technical Specifications:

• Material: Stainless Steel (SS304)

• Gasket Material: EPDM (Ethylene Propylene Diene Monomer) Rubber

• Compatible Profile: Trapezoidal metal sheets (specify height range, e.g., 25mm to 40mm rib height)

• Thread Size: M8 Stainless Steel Stud

• Installation Torque: Recommended tightening torque (e.g., 10-15 Nm)

• Corrosion Resistance: High (Passes 1000+ hour Salt Spray Test)

Parameters

Details
